Milk Packaging Machine / Vertical Form Fill Seal Machine
Main Technical Data: | Model | TD-QL-240L | TD-QL-420L | TD-QL-520L | TD-QL-620L |
| Dosing Mode | Auger Filler | |||
| Bag Shape | 3 or 4 side seal, pillow bag, chain bag | pillow bag | pillow bag | pillow bag |
| Bag Size | L: 55-150mm W: 40-120mm (3 or 4 side seal); W:40-110mm (pillow bag) | L: 80-300mm W: 60-200mm | L: 100-320mm W: 100-250mm | L: 100-450mm W: 100-300mm |
| Packing Speed | 35-70 bags/min | 25-80 bags/min | 25-70 bags/min | 25-60 bags/min |
| Packing Accuracy | 1-10g, ±2-5%; 10-100g, ≤±2% | ≤100g, ≤±2%; 100-500g, ≤±1% | 100-500g, ≤±1%; >500g, ≤±0.5% | |
| Power Supply | 3P AC208-415V 50/60Hz | |||
| Air Supply | 6kg/cm2, 0.2m3/min | 6kg/cm2, 0.25m3/min | 6kg/cm2, 0.3m3/min | |
| Total Power | 3.7kw | 4.7kw | 4.4kw | 5.4kw |
| Total Weight | 300kg | 630kg | 900kg | 1050kg |
| Overall Dimension | 1150*850*2230mm | 1650*1300*2580mm | 1430*1200*2600mm | 1478*1280*2945mm |
| Hopper Volume | 25 L | 35 L | 50 L | 75 L |
FAQ:
1. Manufacturer or trading company : Manufacturer
2. Location : Songjiang district , Shanghai
3. Selling markets: Euope, American, Australia, Asia, Africa
4. Customized: Available for customized designs
5. Delivery time: 15 - 30days
6. Warranty period: 1 year
Product Description:
This machine completes the whole packing procedure of measuring, loading materials, bagging, date printing, charging (exhausting) and products transporting automatically as well as counting. It can be used in powder and granular material, like milk powder, albumen powder, solid drink, white sugar, dextrose, coffee powder and so on.
Main Features:
1. Use intelligent temperature controlling machines to have accurate temperature control ensure the artistic anc neat seal.
2. Use PLC Servo System and pneumatic control system and super touch screen to form the drive control center; maximize the whole machine's control precision, reliability and intelligentized level.
3. PLC & touch screen make it be easy of operation.
4. Have error indicating system, helping to handle the trouble immediately.
5. Make block bags and hanging bags according to customer's different requires.
6. Have stainless steel model and carbon steel model for choosing.
