Paper Bag Making Machine

Product Description

Performance

1. Handle Making Unit

This machine puts a string between two pieces of patch and fixes it together with hot melt glue to make a hand grip.

The handle material can be twisted paper string, twisted p.p. string, acrylic round string ribbon string, also semi-round string etc...The handle making machine is installed parallel to the main machine. It's possible to install it on either side of the main machine, according to the space.

2. Handle (Cardboard) Pasting Unit

Handles or cut cardboard are pasted to the mouth of the main sheet paper to be folded.

This is a sheet paper notch cutting, a mouth pasting, a handle or cardboard applying, folding and pressing unit.

3. Punching Unit

This unit punches two holes for string or four holes for happy tags. In the case of two, there are 3 kinds of punches. (4, 6, and 8mm).

According to the machine type, it's possible to set the interval between holes from 80 to 200mm.

It's now possible to set up a banana type hole cutter optio

SHANGHAI UPG INTERNATIONAL TRADING CO., LTD

Specifications

	Model				KING-45H
Bag Width				Bag	220~450
BottomWidth				Size	70~170
Tube Length			(mm)		320~560
Sheet Width		Sheet Size			610~1260
Sheet Length			(mm)		380~620

		Handle Paper Size			188.4
Handle Paper Cut Length			(mm)

Handle Paper Width					90~100

String Pitch				String	94.2
String Height(mm)				Size	170~185
			(mm)
Mouth Folding (mm)					40~60
Power Consunption(Kw)					30
Main			Machine		2320W
				Size	2710H
			(mm)		14680L
Handle Making Machine					1340W
					2690H
					5410L
Max.Speed(Bags/min)					70
(Handle Size)
(String Dia)	4~8m/m
(Handle Paper Reel Dia) (Max)1000m/m
(Handle Paper Weight)	120~g/m²
